Membránová vakuová čerpadla -NT, Chemistry design
Diaphragm vacuum pumps -NT Series, Chemistry design, Type ME 4C NT , Dimensions (W x D x H) 243 x 255 x 198 mm, max. discharge flow 3.9 / 4.3 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector UK
Výrobce
Zařazeno v kategoriích
Klasické membránové vývěvy
Popis
Diaphragm vacuum pumps -NT Series, Chemistry design
-Improved performance, increased pumping speed and lower ultimate vacuum extend applications in both the laboratory and in industrial applications
-Long-life diaphragm with PTFE sandwich construction and unstressed diaphragm support
-Easy service/exchange of diaphragm or valves due to novel integrated valve head assembly. Easy dismantling, cleaning and reassembly without requiring readjustment
-Very quiet and ultra low vibration due to compact drive with patented motor control system. Ideal as a built-in component for sensitive equipment in both the laboratory and in industry
-Superior vapour tolerance due to integral tubing connections and gas ballast valve for continuous purge (at ME 16C NT, MZ 2C NT, MD 4C / 12C NT and MV 10C NT).
-Easy to clean due to smooth exterior surfaces
The VARIO® design provides vacuum control by precise and continuous adaption of the chemistry diaphragm pumps motor speed, and includes the vacuum pump, as well as the VACUU·SELECT controller.
Specifications
Vacuum inlet: 10mm tubing nozzle
Pressure outlet: 10mm tubing nozzle
Type ME 4C NT
Dimensions (W x D x H) 243 x 255 x 198 mm
max. discharge flow 3.9 / 4.3 m³ / hr.
Ultimate vacuum without / with gas ballast 70 mbar (abs.)
Number of steps 1
Connector UK
-Improved performance, increased pumping speed and lower ultimate vacuum extend applications in both the laboratory and in industrial applications
-Long-life diaphragm with PTFE sandwich construction and unstressed diaphragm support
-Easy service/exchange of diaphragm or valves due to novel integrated valve head assembly. Easy dismantling, cleaning and reassembly without requiring readjustment
-Very quiet and ultra low vibration due to compact drive with patented motor control system. Ideal as a built-in component for sensitive equipment in both the laboratory and in industry
-Superior vapour tolerance due to integral tubing connections and gas ballast valve for continuous purge (at ME 16C NT, MZ 2C NT, MD 4C / 12C NT and MV 10C NT).
-Easy to clean due to smooth exterior surfaces
The VARIO® design provides vacuum control by precise and continuous adaption of the chemistry diaphragm pumps motor speed, and includes the vacuum pump, as well as the VACUU·SELECT controller.
Specifications
Vacuum inlet: 10mm tubing nozzle
Pressure outlet: 10mm tubing nozzle
Type ME 4C NT
Dimensions (W x D x H) 243 x 255 x 198 mm
max. discharge flow 3.9 / 4.3 m³ / hr.
Ultimate vacuum without / with gas ballast 70 mbar (abs.)
Number of steps 1
Connector UK
Varianty produktu
Pro zobrazení cen na míru se přihlašte do klientské sekce.
Kód produktu
Kód produktu
Kód BDL 6268083
Kód BDL 9880944 Kód výrobce
20730102 Type ME 2C NT , Dimensions (W x D x H) 243 x 211 x 198 mm, max. discharge flow 2.1 / 2.4 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector UK
20730102 Type ME 2C NT , Dimensions (W x D x H) 243 x 211 x 198 mm, max. discharge flow 2.1 / 2.4 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector UK
Kód BDL 6267234
Type MZ 2C NT VARIO , Dimensions (W x D x H) 243 x 243 x 245 mm, max. discharge flow 2,8 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector CH
Kód BDL 4672103 Kód výrobce
20743752 Type MD 12C VARIO select , Dimensions (W x D x H) 533 x 260 x 450 mm, max. discharge flow 14.3 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connecto
20743752 Type MD 12C VARIO select , Dimensions (W x D x H) 533 x 260 x 450 mm, max. discharge flow 14.3 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connecto
Kód BDL 4670500 Kód výrobce
20736550 Type MD 4C VARIO select , Dimensions (W x D x H) 243 x 325 x 245 mm, max. discharge flow 4.6 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connector
20736550 Type MD 4C VARIO select , Dimensions (W x D x H) 243 x 325 x 245 mm, max. discharge flow 4.6 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connector
Kód BDL 4670437 Kód výrobce
20732450 Type MZ 2C VARIO select , Dimensions (W x D x H) 243 x 243 x 245 mm, max. discharge flow 2.8 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector C
20732450 Type MZ 2C VARIO select , Dimensions (W x D x H) 243 x 243 x 245 mm, max. discharge flow 2.8 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector C
Kód BDL 9880972
Type MD 12C NT VARIO , Dimensions (W x D x H) 533 x 260 x 420 mm, max. discharge flow 14,3 m³ / hr., Ultimate vacuum without / with gas ballast 1,5 / 3 mbar (abs.), Number of steps 3 , Connector CE
Kód BDL 9880959 Kód výrobce
20743301
Type MD 12C NT , Dimensions (W x D x H) 533 x 260 x 359 mm, max. discharge flow 12.0 / 13.3 m³ / hr., Ultimate vacuum without / with gas ballast 2 / 4 mbar (abs.), Number of steps 3 , Connector CH
20743301
Kód BDL 9880956 Kód výrobce
20741302
Type ME 16C NT , Dimensions (W x D x H) 533 x 260 x 359 mm, max. discharge flow 16.3 / 18.4 m³ / hr., Ultimate vacuum without / with gas ballast 70 / 100 mbar (abs.), Number of steps 1 , Connector
20741302
Kód BDL 9880926 Kód výrobce
20736445
Type MD 4CRL NT , Dimensions (W x D x H) 243 x 325 x 198 mm, max. discharge flow 3.4 / 3.8 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 0.001* mbar (abs.), Number of steps 3 , Connect
20736445
Kód BDL 9880899 Kód výrobce
20732301
Type MZ 2C NT , Dimensions (W x D x H) 243 x 243 x 198 mm, max. discharge flow 2.0 / 2.3 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector CH
20732301
Kód BDL 9880896 Kód výrobce
20734200
Type ME 8C NT , Dimensions (W x D x H) 243 x 325 x 198 mm, max. discharge flow 7.1 / 7.8 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector CEE
20734200
Kód BDL 7101736
Type MD 4C NT VARIO , Dimensions (W x D x H) 243 x 325 x 245 mm, max. discharge flow 4,6 m³ / hr., Ultimate vacuum without / with gas ballast 1,5 / 3 mbar (abs.), Number of steps 3 , Connector CEE
Kód BDL 6267643 Kód výrobce
20734405
Type ME 8C NT + 2AK , Dimensions (W x D x H) 243 x 319 x 374 mm, max. discharge flow 7.1 / 7.8 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector -
20734405
Kód BDL 6311049 Kód výrobce
20743750 Type MD 12C VARIO select , Dimensions (W x D x H) 533 x 260 x 450 mm, max. discharge flow 14.3 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connecto
20743750 Type MD 12C VARIO select , Dimensions (W x D x H) 533 x 260 x 450 mm, max. discharge flow 14.3 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connecto
Kód BDL 4672102 Kód výrobce
20741750 Type ME 16C VARIO select , Dimensions (W x D x H) 533 x 260 x 450 mm, max. discharge flow 20 m³ / hr., Ultimate vacuum without / with gas ballast 70 / 100 mbar (abs.), Number of steps 1 , Connector
20741750 Type ME 16C VARIO select , Dimensions (W x D x H) 533 x 260 x 450 mm, max. discharge flow 20 m³ / hr., Ultimate vacuum without / with gas ballast 70 / 100 mbar (abs.), Number of steps 1 , Connector
Kód BDL 4670495 Kód výrobce
20736402 Type MD 4C NT , Dimensions (W x D x H) 243 x 325 x 198 mm, max. discharge flow 3.4 / 3.8 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connector UK
20736402 Type MD 4C NT , Dimensions (W x D x H) 243 x 325 x 198 mm, max. discharge flow 3.4 / 3.8 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connector UK
Kód BDL 4670425 Kód výrobce
20731202 Type ME 4C NT , Dimensions (W x D x H) 243 x 255 x 198 mm, max. discharge flow 3.9 / 4.3 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector UK
20731202 Type ME 4C NT , Dimensions (W x D x H) 243 x 255 x 198 mm, max. discharge flow 3.9 / 4.3 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector UK
Kód BDL 9880964
Type ME 16C NT VARIO , Dimensions (W x D x H) 533 x 260 x 420 mm, max. discharge flow 19,3 m³ / hr., Ultimate vacuum without / with gas ballast 70 / 100 mbar (abs.), Number of steps 1 , Connector C
Kód BDL 9880958 Kód výrobce
20743302
Type MD 12C NT , Dimensions (W x D x H) 533 x 260 x 359 mm, max. discharge flow 12.0 / 13.3 m³ / hr., Ultimate vacuum without / with gas ballast 2 / 4 mbar (abs.), Number of steps 3 , Connector UK
20743302
Kód BDL 9880955 Kód výrobce
20741300
Type ME 16C NT , Dimensions (W x D x H) 533 x 260 x 359 mm, max. discharge flow 16.3 / 18.4 m³ / hr., Ultimate vacuum without / with gas ballast 70 / 100 mbar (abs.), Number of steps 1 , Connector
20741300
Kód BDL 9880901 Kód výrobce
20736401
Type MD 4C NT , Dimensions (W x D x H) 243 x 325 x 198 mm, max. discharge flow 3.4 / 3.8 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connector CH
20736401
Kód BDL 9880898 Kód výrobce
20732300
Type MZ 2C NT , Dimensions (W x D x H) 243 x 243 x 198 mm, max. discharge flow 2.0 / 2.3 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector CEE
20732300
Kód BDL 9880895 Kód výrobce
20731201
Type ME 4C NT , Dimensions (W x D x H) 243 x 255 x 198 mm, max. discharge flow 3.9 / 4.3 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector CH
20731201
Kód BDL 7101735
Type MZ 2C NT VARIO , Dimensions (W x D x H) 243 x 243 x 245 mm, max. discharge flow 2,8 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector CEE
Kód BDL 6267265 Kód výrobce
20732302
Type MZ 2C NT , Dimensions (W x D x H) 243 x 243 x 198 mm, max. discharge flow 2.0 / 2.3 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector UK
20732302
Kód BDL 4672104 Kód výrobce
20744750 Type MV 10C VARIO select , Dimensions (W x D x H) 533 x 260 x 359 mm, max. discharge flow 9.5 / 10.7 m³ / hr., Ultimate vacuum without / with gas ballast 0.9 / 1.5 mbar (abs.), Number of steps 4 ,
20744750 Type MV 10C VARIO select , Dimensions (W x D x H) 533 x 260 x 359 mm, max. discharge flow 9.5 / 10.7 m³ / hr., Ultimate vacuum without / with gas ballast 0.9 / 1.5 mbar (abs.), Number of steps 4 ,
Kód BDL 4670501 Kód výrobce
20736551 Type MD 4C VARIO select , Dimensions (W x D x H) 243 x 325 x 245 mm, max. discharge flow 4.6 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps , Connector C
20736551 Type MD 4C VARIO select , Dimensions (W x D x H) 243 x 325 x 245 mm, max. discharge flow 4.6 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps , Connector C
Kód BDL 4670438 Kód výrobce
20732451 Type MZ 2C VARIO select , Dimensions (W x D x H) 243 x 243 x 245 mm, max. discharge flow 2.8 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector C
20732451 Type MZ 2C VARIO select , Dimensions (W x D x H) 243 x 243 x 245 mm, max. discharge flow 2.8 m³ / hr., Ultimate vacuum without / with gas ballast 7 / 12 mbar (abs.), Number of steps 2 , Connector C
Kód BDL 9880977
Type MV 10C NT VARIO , Dimensions (W x D x H) 533 x 260 x 420 mm, max. discharge flow 12,8 m³ / hr., Ultimate vacuum without / with gas ballast 0,6 / 1,2 mbar (abs.), Number of steps 4 , Connector
Kód BDL 9880960 Kód výrobce
20744300
Type MV 10C NT , Dimensions (W x D x H) 533 x 260 x 359 mm, max. discharge flow 9.5 / 10.7 m³ / hr., Ultimate vacuum without / with gas ballast 0.9 / 1.5 mbar (abs.), Number of steps 4 , Connector
20744300
Kód BDL 9880957 Kód výrobce
20743300
Type MD 12C NT , Dimensions (W x D x H) 533 x 260 x 359 mm, max. discharge flow 12.0 / 13.3 m³ / hr., Ultimate vacuum without / with gas ballast 2 / 4 mbar (abs.), Number of steps 3 , Connector CEE
20743300
Kód BDL 9880943 Kód výrobce
20730100
Type ME 2C NT , Dimensions (W x D x H) 243 x 211 x 198 mm, max. discharge flow 2.1 / 2.4 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector CEE
20730100
Kód BDL 9880900 Kód výrobce
20736400
Type MD 4C NT , Dimensions (W x D x H) 243 x 325 x 198 mm, max. discharge flow 3.4 / 3.8 m³ / hr., Ultimate vacuum without / with gas ballast 1.5 / 3 mbar (abs.), Number of steps 3 , Connector CEE
20736400
Kód BDL 9880897 Kód výrobce
20734201
Type ME 8C NT , Dimensions (W x D x H) 243 x 325 x 198 mm, max. discharge flow 7.1 / 7.8 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector CH
20734201
Kód BDL 9880894 Kód výrobce
20731200
Type ME 4C NT , Dimensions (W x D x H) 243 x 255 x 198 mm, max. discharge flow 3.9 / 4.3 m³ / hr., Ultimate vacuum without / with gas ballast 70 mbar (abs.), Number of steps 1 , Connector CEE
20731200
