Shaking water bath OLS 26 Aqua Pro
A combined orbital / linear shaking bath for ultimate flexibility and usability. Combined orbital / linear motion in one bath, simply rotate tray carrier 180°

-Excellent temperature stability and uniformity of ±0.1 °C
-Adjustable shaking speed/intensity for application optimisation
-Set and Forgetä technology - fast heat-up accurate temperature control
-Extensive choice of trays for a wide variety of vessels. Trays sold separately
-Includes adjustable high temp cut-off/alarm, countdown timer, presets, calibration facility and dry start/run dry protection
-Discreet magnetically coupled shaking mechanism maximises working area
-Universal frame and polycarbonate lid included

Accessory polypropylene spheres or a lid must be used at temperatures between +60 °C and +99 °C. Accessory cooling is required for temperatures below ambient. Please order PP spheres separately.
Tank size: 26l
Minimum working depth: 70mm
Temperature range: ambient +5 to 99°C (0 to 99°C with accessory cooling)
Uniformity: ±0.1°C
Stability: ±0.1°C
Display: 2 x LED (individual displays & controls for temperature and shaking speed)
Orbital and Linear shaking speed: 20 to 200rpm (depending on load)
Orbital shaking radius: 9mm
Shaking speed display resolution: 1rpm
Linear shaking stroke length: 18, 28, 36 mm
Shaking tray area: 380 x 235mm
Timer: 1 to 999min
Drain Tap: yes
Supply voltage: 220-230V

Type OLS 26
Capacity of the bath 26 litres
Internal dimensions (W x D x H) 298 x 500 x 159 mm
External dimensions (W x D x H) 335 x 565 x 325 mm
Min. speed rpm
Max. speed rpm
Shaking stroke / Shaking orbit mm
Min. operating temperature 5 RT + °C
Max. operating temperature 99 °C
Temperature stability 0.10 ± °C
Bath width 298 mm
Bath tank depth 500 mm
Bath height 159 mm
Width 335 mm
Depth 565 mm
Height 325 mm
Net weight 13.800000 kg
Rated capacity 1.400000 kW
Programmable calibration / temperature deviation +
3 programmable preset temperatures
Programmable timer +
Programmable upper limit
Hingecovering dome
Overtemperature protection
Overtemperature protection
Warning sound +
